CDN-EFT-30 3-Phase Coupling/Decoupling Network for EFT/Burst Test
EMC Test Equipment

3-Phase Coupling/Decoupling Network for EFT/Burst Test

Model CDN-EFT-30 — couples EFT/Burst impulses into the equipment under test while keeping them off the three-phase supply, to IEC 61000-4-4 and ANSI burst-test requirements.

15A max current 8kV max burst 10kV insulation

Description

IEC and ANSI standards cover burst testing of single and three phase AC and DC power ports. The CDN-EFT-30 couples the burst into an EUT while preventing the impulses from polluting the three-phase power supply.

  • Manual coupling-path selection lets you verify each path individually, as recommended by IEC 61000-4-4 Edition 2 (2004).
  • Also supports path-by-path burst testing to ANSI standards, which require it.
  • Available as a 2-channel single-phase version (CDN-EFT-1P) or a 4-channel three-phase version (CDN-EFT-3P).

Technical Specifications

#SpecificationValue
1Max Current15 Amp
2Max Voltage Burst8 kV
3Channels2 (single-phase, CDN-EFT-1P) / 4 (three-phase, CDN-EFT-3P)
4Insulation Level10 kV
5Max AC Voltage415V (Phase–Neutral)
6Weight~8 kg
7Dimensions (W × D × H)[not provided yet]
